Visualizing The Flow Of U.S. Energy Consumption

(Click on image to enlarge)

America Energy Consumption 2020

Graphics/Design: Harrison Schell

Breaking Down America’s Energy Consumption in 2020

The United States relies on a complex mix of energy sources to fuel the country’s various end-sectors’ energy consumption.

While this energy mix is still dominated by fossil fuels, there are signs of a steady shift to renewable energy over the past decade.

This radial Sankey diagram using data from the EIA (Energy Information Administration) breaks down U.S. energy consumption in 2020, showing us how much each sector relies on various energy sources.

The Balance of Energy Production and Consumption

In 2019 and now in 2020, America’s domestic energy production has actually been greater than its consumption—a development that hasn’t taken place since 1957.

Last year’s numbers were severely impacted by the COVID-19 pandemic, seeing a 5% drop in energy production and a 7% drop in consumption compared to 2019. Total energy production and consumption for 2020 came in at 95.75 and 92.94 quads respectively.

The energy amounts are equalized and measured in quadrillion BTUs (British thermal units), also known as quads. A quad is a huge amount of energy, equivalent to 183 million barrels of petroleum or 36 million tonnes of coal.

So how is America’s overall energy production and consumption split between energy sources?

U.S. Energy Production and Consumption Share by Source

(Click on image to enlarge)

Source: IEA

America’s new margin of energy production over consumption has resulted in the country being a net total energy exporter again, providing some flexibility as the country continues its transition towards more sustainable and renewable energy sources.

Fossil Fuels Still Dominate U.S. Energy Consumption

While America’s mix of energy consumption is fairly diverse, 79% of domestic energy consumption still originates from fossil fuels. Petroleum powers over 90% of the transportation sector’s consumption, and natural gas and petroleum make up 74% of the industrial sector’s direct energy consumption.
